ปั๊มจุ่ม LOWARA DL Series

ปั๊มจุ่ม ปั๊มแช่ หรือปั๊มสูบน้ำเสีย DL Submersible pumps with solids-laden wastewater LOWARA

DL series electric pumps, made of cast iron and stainless steel, are available with singlechannel or Vortex impeller (DLV).
Designed to handle solids-laden wastewater, with up to 20 m head and 100 m³/h capacity.
0,6 kW (0.8 HP) to 4 kW (5.5 HP) rated power. Solids handled up to 65 mm in diameter.

SPECIFICATION

• Delivery: up to 42 m³/h
• Head: up to 21 m
• Power supply: both single and three-phase 50 and 60 Hz
• Power: from 0.60 kW up to 1.50 kW.
• Temperature of pumped liquid: to 50 °C
• Maximum immersion depth: 5 m.
• Free passage: up to 50 mm
