ปั๊มจุ่ม ปั๊มแช่ หรือปั๊มสูบน้ำเสีย GSD CP Series submersible sewage pump motor IP68 F Class horizontal impeller 2 mechanical seals with water ingress detection and high temperature motor protection Can be installed with automatic lifters and elbow joints. Suitable for use in wastewater treatment systems in industrial applications, building works, livestock sheds, food industries, chemical industry.
1. Wastewater lift station
2. Municipal wastewater treatment plant
3. Building wastewater treatment system
4. Animal & poultry farm wastewater treatment system
5. Hospital, school, community etc. wastewater treatment system
6. Food, paper, mining, textile, leather, chemical industry etc. wastewater treatment system
7. Water purification system
MOTOR
Squirrel cage, induction motor are F class insulation.The thermal protector is optional to secure the protection of motor against overload & overheating, above 25 HP adopt cooling house to make motor cool.
NON-CLOG IMPELLER
Well statically & dynamically balanced Non-Clog impeller is designed to allow sizable spherical solids to pass the plow passage easily without clogging.
SEAL MECHANISM
The cable assembly is formed to one piece. The mechanical seals protect the motor from contacting the pumping liquids.
AUTO-SETTER (OPTIONS)
To allow pump for easy installation, maintenance & reparation, as it is no need to empty the tank first.
LEAKAGE DETECTOR (OPTIONS)
Built-in leakage detector in the oil chamber can dectet leakage from the damage of the mechanical seal.
HEAT-DETECTOR
Built-in heat protector in motor can prevent the motor from burning out.
Model | Motor | Quantity | Head | Pipe | Weight | |
---|---|---|---|---|---|---|
Hp | Kw | l/min | M | mm | Kg | |
CP-50.75-50 | 1 | 0.75 | 160 | 10 | 50 | 50 |
CP-51.5-65 | 2 | 1.5 | 410 | 10 | 65 | 60 |
CP-51.5-80 | 2 | 1.5 | 650 | 7 | 80 | 60 |
CP-52.2-65 | 3 | 2.2 | 383 | 15 | 65 | 70 |
CP-52.2-80 | 3 | 2.2 | 700 | 9 | 80 | 70 |
CP-53.7-65 | 5 | 3.7 | 500 | 18 | 65 | 130 |
CP-53.7-80 | 5 | 3.7 | 750 | 15 | 80 | 130 |
CP-53.7-100 | 5 | 3.7 | 1250 | 10 | 100 | 130 |
CP-55.5-80 | 7.5 | 5.5 | 583 | 22 | 80 | 180 |
CP-55.5-100 | 7.5 | 5.5 | 1583 | 12 | 100 | 208 |
CP-57.5-80 | 10 | 7.5 | 916 | 22 | 80 | 200 |
CP-57.5-100 | 10 | 7.5 | 1666 | 15 | 100 | 250 |
